ICON 2017+ Ford F-250/F-350 5in Leaf Spring Hardware Kit

Name: ICON 2017+ Ford F-250/F-350 5in Leaf Spring Hardware Kit
Brand: ICON
SKU: ICO65505H
Price: 53.99 USD
Availability: InStock

Roll over image to zoom in Click on image to zoom

ICON

ICON 2017+ Ford F-250/F-350 5in Leaf Spring Hardware Kit

SKU: ICO65505H

No reviews

The ICON Vehicle Dynamics 5” Lift Leaf Spring Hardware Kit ...Read More

Price:

$53.99

Quantity:

Add To Cart

Car Wheel Size Chart

Wheel Diameter (inches)	Tire Width (mm)	Aspect Ratio	Rim Width (inches)
14	185	65	5.5
15	195	60	6.0
16	205	55	6.5
17	215	50	7.0
18	225	45	7.5
19	235	40	8.0
20	245	35	8.5

Note: Wheel and tire sizes vary by car make and model. Always consult your vehicle’s manufacturer for exact specifications.

How to Read Tire Size

Example: 225/45R17 means:

225 = Tire width in mm
45 = Aspect ratio (height as % of width)
R17 = Rim diameter in inches

Ships FAST in USA

Guaranteed Low Price

GGCRACING Discount

Product Details

Product Description

Part Numbers

Sizing & Fit

The ICON Vehicle Dynamics 5” Lift Leaf Spring Hardware Kit eases the installation of ICON leaf springs onto the 2017-2025 Ford F-250 & F-350 Super Duty. Because of the placement of the fuel tank, the driver side front leaf spring hanger bolt cannot be removed without dropping the fuel tank. This replacement bolt kit allows the OE bolt to be cut and removed while leaving the fuel tank in position, and then replaced with a new bolt with the new leaf spring, drastically shortening installation time. Featuring a genuine Ford bolt, you can rest assured that the new mounting bolt is up to the task of securing the new leaf spring in place.

This Part Fits:

Year	Make	Model	Submodel
2017-2025	Ford	F-250 Super Duty	King Ranch
2017-2025	Ford	F-250 Super Duty	Lariat
2018-2024	Ford	F-250 Super Duty	Limited
2017-2025	Ford	F-250 Super Duty	Platinum
2017-2025	Ford	F-250 Super Duty	XL
2017-2025	Ford	F-250 Super Duty	XLT
2017-2025	Ford	F-350 Super Duty	King Ranch
2017-2025	Ford	F-350 Super Duty	Lariat
2018-2024	Ford	F-350 Super Duty	Limited
2017-2025	Ford	F-350 Super Duty	Platinum
2017-2025	Ford	F-350 Super Duty	XL
2017-2025	Ford	F-350 Super Duty	XLT
