ICON 21-23 Ford Bronco Rear Coil Cup Kit

Name: ICON 21-23 Ford Bronco Rear Coil Cup Kit
Brand: ICON
SKU: ICO48201
Price: 176.99 USD
Availability: InStock

Roll over image to zoom in Click on image to zoom

ICON

ICON 21-23 Ford Bronco Rear Coil Cup Kit

SKU: ICO48201

No reviews

The ICON Vehicle Dynamics 2021-2026 Bronco Coil Seat Kit is ...Read More

Price:

$176.99

Quantity:

Add To Cart

Car Wheel Size Chart

Wheel Diameter (inches)	Tire Width (mm)	Aspect Ratio	Rim Width (inches)
14	185	65	5.5
15	195	60	6.0
16	205	55	6.5
17	215	50	7.0
18	225	45	7.5
19	235	40	8.0
20	245	35	8.5

Note: Wheel and tire sizes vary by car make and model. Always consult your vehicle’s manufacturer for exact specifications.

How to Read Tire Size

Example: 225/45R17 means:

225 = Tire width in mm
45 = Aspect ratio (height as % of width)
R17 = Rim diameter in inches

Ships FAST in USA

Guaranteed Low Price

GGCRACING Discount

Product Details

Product Description

Part Numbers

Sizing & Fit

The ICON Vehicle Dynamics 2021-2026 Bronco Coil Seat Kit is used when upgrading an existing pair of ICON 2.5 Series Bronco rear coilovers equipped with spring part number 148350 with the ICON Heavy Rate Rear Coil Kit. Over time different revisions of the ICON triple rate rear Bronco coil have required coil sets of varying heights to achieve proper ride height. This precision CNC machined, anodized aluminum coil cup kit is the correct height to be used with the ICON Heavy Rate Rear Coils to achieve the ICON recommended rear ride height.

This Part Fits:

Year	Make	Model	Submodel
2021-2023	Ford	Bronco	Badlands
2021-2023	Ford	Bronco	Base
2021-2023	Ford	Bronco	Big Bend
2021-2023	Ford	Bronco	Black Diamond
2022-2023	Ford	Bronco	Everglades
2021	Ford	Bronco	First Edition
2023	Ford	Bronco	Heritage Edition
2023	Ford	Bronco	Heritage Limited Edition
2021-2023	Ford	Bronco	Outer Banks
2021-2023	Ford	Bronco	Wildtrak
